SMART WEIGH

Mini 14 Head Multihead Weigher Mini Multihead Weigher Small Volume Weigher

Group Multihead weigher
Min. Order 1 set
Terms of Payment L/C, T/T
Update Time 2020-09-10
Item specifics
ConstructionStainless steel 304
Stainless steel 316Brushed finish
Specification
Model
SW-MS14
Weighing range
1-300 grams
Speed
Max 120 bags/min
Hopper volume
0.5L
Accuracy
±0.8 grams
Drive system
Modular drive
Control panel
7" touch screen
Application
Tea leaves
Small plastic
Grain
Sesame
Features
◆ Mini 14 head weigher is weighing scale with compact design for small weight product, high speed and precision;
◇ Special design to mount on top of VFFS bagger into combine machine, save cost and space;
◆ Servo motor duck mouth timing hopper, collect products into one filling point to reach high speed;
◇ HMI program can be changed according to customize requirement;
◆ Central weight and level sensor checking, double check for all kinds of product features;
◇ AFC auto adjust linear vibration, make sure good accuracy;
◆ Initial program recipe easy for operator setting, and save recipes same as micron office with different name;
Available packing machine
Vertical Packing Line
Rotary Packing Line
Bottle Filling Line
